2 Cabinet A Sub Assy
INDOOR UNIT
PARTS
3 Cabinet B Sub Assy
4 Cabinet C Sub Assy
5
Insulation Box Sub Assy
9 Turbo Fan Washer
1 Top Plate Assy
2012.03.16
9378594012
9378595019
9378570016
9378582026
9378394018
9378395015
Ref. Description Part number
8 Turbo Fan Assy
6 Motor, DC Brushless
7 Motor Rubber
9378228016
9602716005
9378223011
Ref. Description Part number
6
4
1
2
3
5
9
7
8
22
