General AOHG90LRLA - Page 24

57
56
54
53
2017.08.09 23
OUTDOOR UNIT
AOHG90LRLA
Revision code : A
Revision code : None
Closing
Pipe A
9382700003
52
51
Ref. Description
Parts number
54
56
51
Joint pipe distributor 1
Accumulator sub assy
Thermistor assy
9379221085
9900922023
52
Thermistor (heat exchanger) 9900967017
53 Condenser total assy 9382704001
57 Oil return pipe A assy 9378745070
Revision code : None
Revision code : A
