General ASHA30LCC - Page 23

Model :
AOHR30LCT
2006.05.15 22
46
47
48
41
39
36
38
42
37
45
35
33
40
31
CONNECTOR : BLUE
CONNECTOR : ORANGE
DISCHARGE TEMP THERMISTOR
OUTDOOR TEMP THERMISTOR
CONNECTOR : GREEN
COMPRESSOR TEMP THERMISTOR
CONNECTOR : RED
HEAT EXCHANGER THERMISTOR
CONNECTOR : RED
PRESSURE SWITCH WIRE
