When you order parts, please make a photocopy of this page
and fill the number of the parts in the "Order" column.
INDOOR UNIT
PARTS LIST
Ref.
No.
Description
Part No.
ASHA30LCC
Ord.
Q'ty
1 Front Panel Total Assy 9315335043
2 Intake Grille Assy 9315336033
4 Air Filter 9315014016
5 Clamper (Grille) 9306755010
6 Receiver Window 9315010018
8 Crossflow Fan Assy 9315024015
9 Bearing C Assy 9306628017
10 Casing Assy 9315331021
22 R and L Louver 9311997016
23 Spacer B 9312441013
26 Drain Cap 9367677009
27
Evaporator Assy
9315348012
28
Evaporator Assy B
9315349019
25 Evaporator Assy C 9315789013
29
Connection Pipe Assy
9315355010
30 Distributor Assy 9315351012
31 Water Seal 9315251015
32 Evaporator Holder R 9314994012
33 Evaporator Holder L 9314995019
34 Rear Bracket 9315022011
35 Filter Guide 9315013019
36 Filter Guard 9315411013
37 Controller PCB Assy 9707090062
38 Control Box 9314996016
39 Control Cover 9314997013
40 Case (Motor) 9314998010
41 Terminal (Earth) 9315028013
42 Motor, DC Brushless 9602163014
46 Motor, Step 9900384029
47 Motor, Step 9900384036
48 Motor, Step 9900139063
52 Gear A 9309994003
53 Terminal 9900385019
55 Indicator PCB Assy 9707210019
2006.05.15 23
To Next Page
