27 Drain Pump Sub Assy
28
29
Float Switch Sub Assy
26 Fan Motor (09, 12) 9603283018
26 Fan Motor Assy (07) 9603139018
9379914024
9378593022
Drain Hose Assy 9379913003
30 Hose Sub Assy 9378450097
Parts numberDescriptionRef
Top Panel Sub Assy21
Sirroco Fan Assy22
23
Rubber (Vibration Proof)
Casing B24
9379908030
9379570015
9379644006
9379572019
25 Casing U 9379571012
Parts numberDescriptionRef
712013.06.20
INDOOR UNIT
SLIM DUCT
ARHG07LLTA
ARHG09LLTA
ARHG12LLTB
(Serial number : R)
21
27
30
29
22
25
24
26
28
23
