bulb temperature is the temperature you
feel when your skin is wet and exposed to
moving air as opposed to the actual air
temperature—the dry bulb temperature.
The EP8709 is powered by one “9V” battery
(included).
KEY FEATURES
• Jumbo backlit display with 2-line readout
• Field calibratable using optional 33% and
75% salts
• Data hold and Min/Max functions
• °F/°C switch
• 20-minute Auto Power Off function
• Low battery indicator
WHAT’S IN THE BOX
The EP8709 comes fully assembled in a box
along with a sensor protection cap, a “9V”
battery and this user’s manual.
PRODUCT OVERVIEW
Figure 1 shows all of the controls, indicators
and physical structures on the front, top and
bottom of the EP8709. Figure 2 shows all
text and icons that could appear on the
unit’s LCD. Familiarize yourself with the
positions and functions of all buttons,
structures and icons before moving on to
the Setup Instructions and Operating
Instructions.
4
