SETUP INSTRUCTIONS
INSTALL BATTERY
1. The meter’s battery compartment (Fig. 1,
Callout I) is accessible from the bottom of
the unit. Use a Phillips-head screwdriver
to loosen the single screw in the back of
the unit that holds the yellow battery
compartment cover in place. Set the
cover and screw aside.
2. Plug the included “9V” battery into the
wired socket inside the compartment. The
terminals of the battery and the socket
mate in only one way, with the smaller
male terminal plugging into the larger
female terminal.
3. Replace the battery compartment cover
and tighten the screw to secure it to the
housing.
OPERATING
INSTRUCTIONS
MAKING BASIC
MEASUREMENTS
Before making any measurements, rotate
the sensor protection cap with your thumb
and index finger so its three vents are open
to the ambient environment from both the
front and back. Press the button to
power on the meter. The dual displays will
7
