General GEM130 User Manual

GEW130 Mixer operation instruction Rev. a
8. list of part number
Date 2005-1-1
# Part # Description # Part # Description
1 SM300-01-09 cover 41 SM300-01-04 case
2
外购件
flat valve cap 42 SM300-01-40 worm wheel
3 SM300-01-14 top batter valve cap 43 standard part pin
4 203 bearing 44 SM300-01-41 bushing
5 SM300-01-05
transmission shaft
support 45
外购件
motor rotator
6 SM300-01-16 spacer-lower 46
外购件
motor stator
7 SM300-01-13 gear 47 SM300-01-03
back bearing
suppoter
8 SM300-01-19-01 gear 48 SM300-01-45 back cover, Motor
9 SM300-01-19-02 gear 49 SM300-01-24 plug attachment hub
10 SM300-01-20 gear 50 SM300-01-01 plug
11 SM20-01-21 bushing 51 SM300-01-23 attachment hub
12 SM300-01-25 sleeve 52 SM20-01-26 ring
13 SM300-01-17 main shaft 53 SM300-01-22 gear
14 standard part
retainer-spring(shift
er yoke) 54 SM300-01-18 handpiece
15
外购件
spring 55 SM300-01-30 internal gear
16 standard part pin 56 SM300-09-03 Flat Beater
17 SM300-01-27 bushing 57 SM300-08-00 bowl
18 standard part bearing 58 SM300-01-32 hood ring
19 SM300-01-06 shaft worm gear 59 Spring-59 spring
20 SM300-01-10 gear 60 SM300-01-31 planet
21 standard part bearing 61 standard part bearing
22 SM300-01-26 gear 62 SM300-01-33 operating shelf
23 standard part bearing 63 SM300-01-34 working shaft
24 seal-24 #24, oil seal 64 standard part bearing
25 standard part nut 65 seal-65 #65, oil seal
26 standard part nut 66 SM20-01-39-01 cam-gear shifter
27 standard part bearing 67 SM20-01-39-02 plate-shifter index
28 SM300-09-01 Wire Whip 68 SM300-01-02 handle-shifter
29 SM300-01-11 gear 69 SM300-06-11 crank lever
30 SM300-01-38 bushing 70 SM300-06-10 connecting rod
31 SM300-01-35 gear 71 SM300-06-09 angle iron
32 standard part bearing 72 standard part nut
33 SM300-09-02 hook 73 standard part ring
34 standard part pin 74
外购件
spring
35
外购件
spring 75 standard part nut
36 standard part
retainer-spring(shift
er yoke) 76 SM300-06-12 handle-shifter
37 SM300-01-42 shifting yoke 77 SM300-06-01 stud
38 SM300-01-43 declutch shift shaft 78 SM300-06-05 support
39 standard part nut 79 SM300-06-06 base
40 SM300-01-12 gear shaft 80 SM300-06-07 slide squeeze head
81 SM300-03-01-00 Safety guard
page 6 of 6

General GEM130 Specifications

General

Brand	General
Model	GEM130
Category	Mixer
Language	English
