REPLACEMENT PARTS
LIST
MODEL: SM-12A
KEY
QTY
NO PART NO NAME: DESCRIPTION MACH
1 09-SM-1722 BUTTON: DEBURRING STONE 1
2 08-SM-6050 NUT: STONE MTG 1
3 06-SM-6051 FIBER WASHER 1
4 09-SM-1327 DEBURRING STONE (GRAY) 1
5 09-SM-1317 SHAFT: DEBURRING STONE 1
6 08-SM-1323 SPRING: DEBURRING STONE 1
7 08-SM-6050 NUT: STONE MTG 1
8 06-SM-6051 FIBER WASHER 1
9 09-SM-1203 STONE: SHARPENING 1
10 09-SM-1318 SHAFT: SHARPENING STONE 1
11 08-SM-1322 SPRING: SHARPENING STONE 1
12 08-SM-1102 WASHER: FLAT 6 MM 1
13 09-SM-1208 KNOB: SHARPENING HSG/KNIFE COVER 1
14 23-SM-1320 SHARPENER HOUSING 1
30-SM-1320 SHARPENER ASSY COMPLETE 1
15 08-SM-1210 SCREW: CSK HD 6MA X 12 1
16 08-SM-1211 NUT: TUBE SHAFT 1
17 08-SM-1336 RETAINING RING: STONE SHAFT 2
18 30-SM-1202 SHARPENER FRAME ASSY 1
(INC: 1-12, 16-18, 21 &22)
19 08-SM-1204 WASHER: FLAT 4MM 2
20 08-SM-1012 SCREW: PN HD 4MA X 10 2
21 23-SM-1202 TUBE SHAFT, NUT & FRAME 1
(INC: 16, 18,21 &22)
22 30-SM-1207 MTG POST ASSY: SHARPENER 1
22A 08-SM-1035 SCREW: SET 8MAX 8 1
23 23-SM-1319 REGULATOR PLATE 1
24 09-SM-1208 KNOB: SHARPENER HSG/KNIFE COVER 1
24A 09-SM-1223 ROD: KNIFE COVER 1
25 08-SM-1216 NUT: HEX 14MA X 6 1
26 08-SM-1217 WASHER: FLAT 14MM X 1 1
27 23-SM-1212 KNIFE HOUSING 1
28 08-SM-1218 SPACER: KNIFE PULLEY, 23MM 1
08-SM-1340 SPACER: KNIFE PULLEY SHAFT 1
29 30-SM-1220 KNIFE PULLEY ASSY 1
(INC: 28, 29, BRG & SHAFT)
• 09-SM-1222 PULLEY SHAFT 1
* 09-SM-1219 BEARING (CALL FACTORY) 2
30 06-SM-1221 BELT: TB2-34-660 (THRU S/N 110598BD012) 1
06-SM-1370 BELT: TB2-630 (S/N 110598BD013 FWD)
31 09-SM-1224 KNIFE: 12" 1
09-SM-1307 KNIFE: 12" SS 1
32 08-SM-1220 SCREW PN HD 5MAX 10 3
33 23-SM-1299 KNIFE COVER 1
34 08-SM-1427 THUMBSCREW: KNIFE COVER 1
35 08-SM-1441 THUMBSCREW: KNIFE WIPER 2
36 09-SM-1284 KNIFE WIPER 1
37 08-SM-1514 WASHER: STAR 8MM 2
38 08-SM-1214 SCREW: HXHD 8MAX 30 2
39 23-SM-1345 BASE 1
40 09-SM-1253 PLATFORM RAIL 1
41 08-SM-1073 SCREW: HXHD 5MAX 10 2
42 09-SM-1231 REGULATOR KNOB 1
43 08-SM-1232 BUSHING: REGULATOR KNOB 1
44 09-SM-1301 REGULATOR CAM: 30MM 1
45 08-SM-1091 USE P/N 08-SM-479 2
46 30-SM-1228 RATCHET PIN ASSY 1
47 05-6-1503 RUNNING LIGHT: 115V 1
48 05-6-4581 GUARD: TOGGLE SWITCH 1
49 05-6-1501 SWITCH: TOGGLE, 120V 1
05-6-1507 SWITCH: TOGGLE, 230V 1
49A 12-6-1779 LABEL: ON/OFF 1
49B 06-6-2192 BOOT: TOGGLE SWITCH 1
50 30-SM-1233 BRACKET: REGULATOR SPRING 1
51 08-SM-1333 SCREW: SKHD 6MA X 16 1
52 08-SM-1234 SPRING: REGULATOR 1
53 08-SM-1235 SCREW: PN HD 6MA X 10 1
55 08-SM-1267 NUT: CAM FOLLOWER 1
56 06-SM-1267 CAM FOLLOWER PIN 1
57 01-SM-1237 REGULATOR SLIDE 1
58 08-SM-1236 SLIDE BUSHING 2
59 09-SM-1363 BRACKET: REGULATOR SLIDE 2
60 08-SM-1063 NUT: JAM HEX 6MM 2
KEY
QTY
NO PART NO NAME: DESCRIPTION MACH
61 08-SM-1054 SCREW: HXHD 6MA X 20 1
62 08-SM-1333 SCREW: SKHD 6MA X 16 4
63 08-SM-1226 WASHER: FLAT 8MM X 26 2
64 08-SM-1302 WASHER: LOCK SPLIT 8MM 2
65 08-SM-1227 SCREW: HXHD 8MAX 30 2
66 08-SM-1334 BUMPER: MOTOR ADJUSTMENT SCREW
67 08-SM-1515 NUT: HEX 8MA 1
68 08-SM-1515 NUT: HEX 8MA 1
69 08-SM-1247 SCREW: BELT TENSION ADJ 1
70 30-SM-1246 MOTOR: 115V/60HZ (THRU S/N 110598BD012) 1
30-SM-1371 MOTOR: 115V/60HZ; SM12A NS 1
(S/N 110598BD013 FWD)
30-SM-1230 MOTOR: 220V/50HZ 1
09-MM-9541 BEARING: #6201 2
05-SM-1367 WIRE: MOTOR GROUND 1
08-SM-1235 SCREW: PN HD 6MAX 10 3
05-SM-6125 GROUND TAG 3
08-SM-6127 WASHER: STAR 5MM 3
08-SM-6126 SCREW: PN HD 5MA X 8 1
71 09-SM-1364 RETAINING RING: MOTOR MTG 2
72 09-SM-1347 BRKT, MTG: MOTOR SM-12A 1
73 08-SM-1333 SCREW: SKHD 6MA X 16 2
74 08-SM-1365 POST: MOTOR MTG 1
75 05-SM-1245 CAPACITOR: 10MF, 450V 1
(THRU S/N 110598BD012)
05-SM-2032 CAPACITOR: 20MF, 450V 1
(S/N 110598BD013 FWD)
76 08-SM-1224 CLAMP: CAPACITOR 1
77 08-SM-1117 SCREW: ST PN HD 39 X 10 1
78 05-SM-1506 STRAIN RELIEF 1
79 05-GSM-756 CORDSET 1
80 08-SM-1117 SCREW: ST PN HD 39 X 10 4
81 08-SM-1240 WIRE CLAMP 4
82 09-SM-1329 BOTTOM COVER: SM-12A 1
83 06-SM-1463 FOOT: 45MM H W/6MA STUD 4
84 30-SM-1359 SPIKE PLATE ASSY (INC: 84,90 & 91) 1
85 30-SM-1289 FOODPUSHER ASSY (INC 84-91) 1
86 08-SM-1362 SCREW: FOODPUSHER STORAGE 1
87 08-SM-1016 NUT: JAM HEX 6MA 1
88 08-SM-1264 SCREW: SET 10MAX 30 1
89 30-SM-1265 HANDLE ASSY W/STUD 1
90 06-SM-1360 NYLON WASHER: FOODPUSHER 1
91 09-SM-1490 KNOB: SM W/6 MM FEMALE THREAD 1
92 09-SM-1269 SHAFT: FOODPUSHER 1
93 09-SM-1283 LOCK KNOB: SHAFT 1
94 23-SM-1270 PLATFORM 1
95 23-SM-1273 PLATFORM BRKT 1
96 09-SM-1272 HANDLE: PLATFORM 1
97 09-SM-1274 KNOB: PLATFORM 1
98 08-SM-1271 SCREW: HXHD 5MAX 15 1
99 08-SM-1102 WASHER: FLAT 6MM 2
100 08-SM-1080 NUT: HEX 6MM 1
101 08-SM-1282 SCREW: HXHD 6MA X 25 1
102 06-SM-1540 ROLLER: PLATFORM 1
103 08-SM-1102 WASHER: FLAT 6MM 1
104 09-SM-1275 ROLLER BRKT 1
105 08-SM-1278 SCREW: RND HD (RLR BRKT) SS 2
106 08-SM-1226 WASHER: FLAT 8MM X 26 2
107 08-SM-1514 WASHER: STAR 8MM 2
108 08-SM-1261 SCRDW:SCKHD 8MAX 15 2
109 08-SM-1260 WASHER: SHAFT 2
110 09-SM-1252 SHAFT EXTENSION 1
111 06-SM-1259 WASHER: RUBBER 2
112 08-SM-1337 WASHER: PLATFORM SHAFT 2
113 08-SM-1258 BUMPER: SPRING SHAFT 2
114 09-SM-1254 PLATFORM SHAFT 1
115 01-SM-1255 PLATFORM CARRIAGE 1
116 08-SM-1251 STUD: PLATFORM BRKT 10MM X 38 1
117 08-SM-1256 SCREW: HXHD 6MA X 20 NYLON 1
118 08-SM-1257 SCREW: SET (CARRIAGE) 1
119 06-SM-1346 WASHER: RUBBER 1
120 08-SM-1303 SCREW: PLATFORM BRKT 1
• Not Pictured.
General Slicing/Red Goat Disposers • 1152 Park Avenue • P.O. Box 428 • Murfreesboro, TN 37133-0428 • (615) 893-4820
Effective: April 1, 1999
