CLEANING (continued)
REASSEMBLY
Knife Cover
1. Re-install the knife cover by positioning it in the center of the
knife hub, rotating it slightly back and forth until it nests over
blade.
Note: The grooves on the front of the knife cover should be
horizontal, as on the regulator plate.
2. Replace the knob and rod assembly, and tighten by turning it
clockwise until snug.
Note: Do not overtighten.
Knife Sharpener
1. Position sharpener as shown and slide the sharpener shaft into
the mounting bracket, until stop is reached.
2. Turn counter-clockwise 90° and continue pushing down until
second stop is reached.
Note: The sharpening and deburring stones should be behind
blade and not in contact.
Platform Assembly
1. Tilt the platform back toward regulator plate, and replace and
tighten the lock knob by turning it clockwise.
7
