The Regulation of Accelerograph Tight wire
1. When you want to check valve’s artificial switch in the left, right of whole turning orientation, from
whole opening orientation to whole closing orientation, whether they are agility or not.
2. To measure free extent of valve’s artificial switch at side of valve’s artificial switch. The standard of
free extents: 10°～15°
If you want to adjust free extent, you should relax screw and regulate adjustor
Clutch’s regulation
Before the clutch was become loosing, Clutch’s free extent focus on clutch’s controller, free extent is 10 to
20mm.
If you find it is abnormal, you can take the following adjustments:
1. To loosen lock nut A
2. To screw on or off adjust nut B, and then make free journey catch the stated requirements
3. To screw down lock nut A
