Note
: Depending upon system pressure and other factors, it is possible to observe flow to drain in the rest cycle.
-When the valve is between positions, the display will flash the number of the step it is moving towards.
-The default time at which regeneration will occur is 12:00 a.m.
The motor’s run direction during a particular regeneration cycle step is indicated by the rotation direction of the
last 2 digit displays.
Example:
5
-
Programming the Control Valve
Master Programming Mode
To enter Master Programming Mode, press and hold both buttons for 5 seconds.
Note: All Master Programming functions have been preset at the factory. Unless a change is advised by your dealer, it is
NOT necessary
to enter Master Programming Mode.
Example (r12A)
1. Regeneration Time (r)
- Default regeneration time setting is 12A
2. Backwash Cycle Step Times* (Steps 2, 3, 4, 5)
Example ( 3 - 20 )
- The next 4 displays set the duration of time in minutes for each backwash cycle step.
- The step number which is currently modifiable is indicated on the far left of the display screen.
- The number of minutes allotted for the selected backwash step is displayed on the far right.
- Change the digit values using the Set/Change and Menu/Enter buttons as described above.
Note on Air Draw Cycle (4):
The longer the unit is set to remain in the Air Draw cycle (4), the more air is drawn into the system. A default
setting of 20 minutes draws air down to the level of a normal media bed height. If the system needs more air,
increase the time setting for step (4) or decrease the number of days between air draw cycles.
BE 1 (ON)
BE 0 (OFF)
3. Bluetooth Enabled
4. Bluetooth Password
BtPP is displayed for one second, then password is displayed.
Example ( A)
- To change digit value, press the Set / Change button.
- To accept the digit value, press the Menu / Enter button.
- Next digit will flash to begin setting.
- Once the last digit display is accepted, all digits will flash.
5. To Exit the Master Programming Mode, press the Menu / Enter button until time of day returns.
Note: If no buttons are pressed for 60 seconds, the Master Programming Mode will be exited automatically.
- The time of day at which regeneration may take place is designated by the letter “r”.
- The first display digit indicates A.M. or P. M. To change the value, press the Set/Change button.
- Press Menu/Enter button to accept the value and move to the next digit.
- The second and third display digits indicate the hour at which the regeneration will occur.
- Change the digits with the Set/Change button and accept with the Menu/Enter button.
- After the entire display flashes, press the
Menu/Enter button to move to the next menu item.
