9. Important additional information
23
Jump Starting
9.1 Emergency Starting
• Do not attempt to jump start the high voltage battery.
• Do not connect the cables to or near any part that moves when the vehicle is started.
• Do not allow the jumper cables to contact anything except the correct battery
terminals or the correct ground.
• Do not lean over the battery when making connections.
5. Start the vehicle with the booster battery, then start the vehicle with the discharged
battery.
6. After a few minutes, turn off the both vehicles.
7. Remove the negative terminal cable first and then remove the positive terminal cable.
1
. Position the vehicles close enough that
the jumper cables will reach, but do not
allow the vehicle body parts to contact.
2. Avoid any moving parts in the PE room.
3. Turn off all unnecessary electrical loads.
4. First connect one end of a jumper cable
to the positive(+) (1)terminal of the
discharged battery in the PE room, then
connect the other end to the positive(+)
(2)terminal on the booster battery.
Proceed to connect one end of the other
jumper cable to the negative(-) (3)terminal
of the booster battery, then the other end
to a solid, stationary, metallic point (4).
If the cause of your battery discharging is not apparent, we recommend that the
system be checked by an authorized GENESIS dealer
.
-
+
