Genesis Electrified G80 - High Voltage System Cut-off

4. Disconnect the High voltage cut-off switch.
3. Disable direct hazards / safety regulations
7
a) Remove the Junction block upper cover “A” in the PE (Power Electric) room,
located under the front hood.
b) Disconnect the High voltage cut-off Switch “B” using the following procedure :
① : Pull the label → ② : Disconnect
B : High voltage
cut-off Switch
5. Remove the High voltage cut-off Switch located in the low voltage junction block.
