5.8A, 4-3/4" Dry Cut Metal Saw
Operator’s Manual GMCS547C
KNOWING YOUR DRY CUT METAL SAW
1. Base
2. Lower Blade Guard Lever
3. Lower Blade Guard
4. Saw Blade (GAMCSB471)
5. Blade Clamping Bolt
6. Outer Blade Flange Washer
7. Cut Visibility Window
8. Chip Collection Chamber
9. Upper Blade Guard
10. Soft Grip
11. ON / OFF Trigger Switch
12. Lock-Off Button
13. Allen Key and Holder
14. Spindle Lock
15. Depth Clamp Lever
16. Depth Guide Bracket
17. Rip Fence Locking Screw
FIG 1
1
2
3
4
5
6
7
8
9
10
11
12
13
14
16
17
15
