GENESIS GV60
FEATURES AND CONTROLS
EV DTE TIPS
EV DISTANCE TO EMPTY (DTE) TIPS
- When the vehicle is charged, DTE displayed in the
instrument cluster is calculated based on previous
operating patterns.
- Distance to Empty (DTE) may depend on many factors
such as high voltage battery % charge, weather, temperature, battery
condition, geographical features (hills driven recently), and driving style.
1. After you first receive your vehicle, the accuracy of the DTE gradually
increases by learning your driving pattern (air conditioning/heating
usage, weather, driving pattern - including average vehicle speed).
2. The more the HVAC air conditioner / heater is used, the less energy
is available for driving range. Use seat heater & steering wheel heater
(if equipped) or pre-conditioning while still plugged in to reduce the
need for cooling / heating while driving.
3. It is recommended to set the cabin temperature to 72°F AUTO. This
setting provides optimal energy consumption rates while maintaining
a constant temperature.
4. Depress and hold the accelerator pedal smoothly to maintain speed
and to drive economically. Maximize the use of regen
braking to charge battery when reducing speed.
Adjust regen braking level and settings to your
preference.
5. When using the heater or air conditioning system
use the DRIVER ONLY or scheduled air conditioner /
heater function.
COLD WEATHER TIPS
1. EV battery energy consumption is increased by cold or hot
temperatures. It is far more noticeable in cold weather.
2. When using the heater during cold weather, the high voltage battery
consumes more energy. This may reduce the distance to empty
significantly. Usage of seat & steering wheel heater in lieu of heater
does not affect DTE.
3. In cold weather, pre-scheduled heating helps enhance electric
vehicle performance by heating the vehicle in advance.
You can also use Genesis Connected Services to remotely set the
cabin temperatures while charging (subscription required.)
4. Select Winter / Battery Conditioning
Mode in EV Settings to increase
battery temperature during winter
to improve driving & DC charging
performance, however this will
reduce DTE
5. “Power Limited Due to Low EV
Battery Temperature, Charge
Battery” warning message is
displayed to protect the electric vehicle system when outside
temperature is low.
