Channel 4 - Rotating gobo wheel
Channel 5 - indexing & Rotating gobo rotation
Rotating gobo angle zero to 360 degrees. adjustment from
Forwards gobo rotation from fast to slow
Backwards gobo rotation from slow to fast
127
191
255
0
128
192
4
Channel 6- Prism-wheel
Open position
Triple prism static
Triple prism forwards rotation from fast to slow
Triple prism backwards rotation from slow to fast
Triple prism static
1
7
132
253
255
0
2
8
133
254
Channel 7- Focus
Focus adjustment from near to far
255
0
Channel 8- Pan reguration
CH-11
The head of the unit is allowed to turn horizontally from
zero to 570 degrees.
5
6
7
8
