Genius BRAIN 15 User Manual

BRAIN 15
ENGLISH
Guide for the installer
Pagina 22
Tab. 13
LOGIC “C” MAINTAINED COMMANDS PULSES
AUTOMATED
SYSTEM STATUS
OPEN A OPEN B STOP FSW OP FSW CL FSW CL/OP
CLOSED opens the leaves no effect
no effect (OPEN
disabled)
no effect (OPEN
disabled)
no effect
no effect (OPEN
disabled)
OPENING no effect closes leaves stops operation locks operation no effect locks operation
OPEN no effect closes leaves
no effect (OPEN/
CLOSE disabled)
no effect
no effect (CLOSE
disabled)
no effect (OPEN/
CLOSE disabled)
CLOSING opens the leaves no effect stops operation no effect locks operation locks operation
BLOCKED opens the leaves closes leaves
no effect (OPEN/
CLOSE disabled)
no effect (OPEN
disabled)
no effect (CLOSE
disabled)
no effect (OPEN/
CLOSE disabled)
a If the cycle began with OPEN-B (released leaf), both leaves are activated at opening
