Genius DIABLO - EU DECLARATION OF CONFORMITY; DECLARATION OF INCORPORATION FOR PARTLY COMPLETED MACHINERY

INDEX
IMPORTANT NOTES FOR THE INSTALLER page.7
TECHNICAL SPECIFICATIONS page.7
DESCRIPTION OF THE COMPONENTS page.7
INSTALLATION page.7
Electrical preparations (standard system) Fig. 4. page.7
Preliminary checks page.7
Walling in the supporting box page.7
Installing the leaf page.8
Installing the gearmotor page.8
Electrical connections page.8
START-UP page.8
MANUAL OPERATION page.8
RESTORING NORMAL OPERATION page.8
AVAILABLE ACCESSORIES page.8
Encoder page.8
Mechanical stops page.8
MAINTENANCE page.8
REPAIRS page.8
SPECIAL APPLICATIONS page.8
EU DECLARATION OF CONFORMITY
The Manufacturer
Company name: FAAC S.p.A. Soc. Unipersonale
Address:
Via Calari, 10 - 40069 Zola Predosa - BOLOGNA
- ITALIA
hereby declares under his sole responsibility that the following product:
Description: Underground actuator for swing gates
Model: DIABLO
Complies with the following relevant Union harmonization legislations:
2014/30/EU
2011/65/EU
Furthermore, the following harmonised standards have been applied:
EN 61000-6-2:2005
EN 61000-6-3:2007 + A1:2011
Bologna, 19-03-2018 CEO
A. Marcellan
DECLARATION OF INCORPORATION FOR PARTLY
COMPLETED MACHINERY
(2006/42/EC ANNEX II P.1, B)
Manufacturer and person authorised to draft the applicable technical
documentation
Company name: FAAC S.p.A. Soc. Unipersonale
Address:
Via Calari, 10 - 40069 Zola Predosa - BOLOGNA
- ITALIA
Hereby declares that the partly completed machinery:
Description: Underground actuator for swing gates
Model: DIABLO
the following essential requirements of the Machinery Directive
2006/42/EC (including all applicable amendments) have been ap-
plied and fullled:
1.1.2, 1.1.3, 1.1.5, 1.1.6, 1.3.1, 1.3.2, 1.3.4, 1.4.1, 1.4.2.1, 1.5.1,
1.5.5, 1.5.6, 1.5.8, 1.6.1, 1.6.4, 1.7.1, 1.7.2, 1.7.3, 1.7.4.2, 1.7.4.3
and that the relevant technical documentation has been compiled in
compliance with part B of Annex VII.
Furthermore, the following harmonised standards have been applied:
EN12100:2010
EN13849-1:2015
EN13849-2:2012
Other applied standards:
EN 12453:2017
Undertakes to transmit by mail or by e-mail, in response to a reasoned
request by the national authorities, relevant information on the partly
completed machinery.
It is also declared that the partly completed machinery identied above
may not be commissioned until the nal machine - into which it will be
incorporated - has been declared complaint with the provisions of the
above mentioned Machine Directive 2006/42/EC.
Bologna, 19-03-2018 CEO
A. Marcellan
