Service Guide SW-5.1 1020
1.2.10 VOL (Volume) Inoperative
Version No. 1.0 Page 16 of 24
VOL inoperative
1. VR2 potentiomete
r
defective or damaged
2. Power failure of U6 volume
integrated circuit
3. Broken circuit/ short circuit of
PCB
4. Such elements damaged as
D6, R59, JK5 and U6
Replace/ repair
