12
STARTING UP THE GENERATOR
Remove the load from all output ends;
1.
Connect the positive and negative electrodes of the battery;
2.
Select the Fuel:
a. Gasoline: Turn the fuel source switch to gasoline.
b. LPG:
1. Connect the LPG hose to the LPG tank;
2. Tighten the other end of the LPG hose to the generator intake;
3. Turn the fuel source switch to LPG.
3.
1. 2. 3.
Turn the choke lever to the "CLOSED" position;
Tip: Don't close the choke when starting the engine in warm state.
5.
Select Boot Mode:
a. Hand Starting: Pull the starting handle to
start the generator.
b. Electric Start: Press the engine switch
upward to the Start position "Start" for 2-3 s.
6.
Turn the choke lever to the "OPEN" position;
7.
To Next Page
