GENMAX GM12000ED - CIRCUIT DIAGRAM; Generator Schematic

27
TECHNICAL PARAMETERS
Item
GM12000ED
Engine Model
Engine Type
Displacement (cc)
Gas Distribution Mode
Cooling Mode
Rated Speed (RPM)
Starting Method
Fuel Tank Volume (gal)
Fuel Type and Grade
Lubricating Oil Capacity (gal)
Lubricating Oil Model
192F/P-2
458
OHV
Forced cooling wind
3600
Recoil start/Electrical start
10.6
Vehicle-use unleaded gasoline
SAE 10W/30
0.3
Noise dB (at 7m)(25% load)
Rated Power (kW)
Max. Power (kW)
Rated Voltage (V)
Rated Frequency (Hz)
Rated Power Factor
Phase Number
77
9000(GAS.)/8000(LPG)
10000(GAS.)/9000(LPG)
120/240
60
1
Single phase
Run Time @ 25% (h)(GAS.)
16
Overall Dimension (in.)
Net Weight (lb.)
27.9x21.1x24.6
218.3
Stroke x Bore (mm)
92x69
4-stroke
Fuel Consumption Rate
(25% load)(L/h)
THD
Fuel Consumption Rate
(100% load)(L/h)
2.5
5
≤23%
LPG Consumption Rate
(25% load)(kg/h)
LPG Consumption Rate
(100% load)(kg/h)
1.1
2.1
Valve Clearance
Input valve：0.10~0.15 mm, Output valve：0.15~0.20 mm
