INSTALLATION OF WHEELS AND HANDRAILS
Align the two holes on the support seat with the
two holes on the bottom of the frame. Place two
bolts through the support seat hole and the frame
hole;
1.
Install the Wheel
Fasten the nut to the bolt, tighten with a wrench.
Install the other side in the same way.
2.
Install Support Foot
Put the axle through the wheel and the gasket,
connect to the rack;
1.
Insert the R pin into the hole in the wheel shaft. Install the other side in the
same way.
2.
Install Handrails
Place two gaskets into the holes on the left and
right sides of the handle, bolt the handle to the
frame;
1.
Fasten the nut to the bolt, tighten with a wrench. Install the other side in the
same way.
2.
