Genmitsu 3020-PRO MAX CNC - Install the Limit Switches

Step 2: Install the Limit Switches
What you will need
Align the X-axis, Y-axis and Z-axis limit switches with the screw holes and tighten the M2.5 Screws.
For the Y axis one, please use the M2.5*12 Screw, for the X axis and Z axis, use the M2.5*10 Screws.
26
4 x M2.5*10 Screw
3 x Limit Switch (60cm)
14
M2.5x12 Screws
Limit Switch
M2.5x10 Screws
11
2 x M2.5*12 Screw
27
