Genmitsu 3020-PRO MAX CNC - Install the Spindle

14
Step5: Install the Spindle
What you will need
Spindle with ER11 Tail (300W/12000RPM)
Spindle Motor
M5 Hex Screws
1. Loosen the M5 Hex Screws of the spindle motor holder.
2. Insert the spindle into the spindle motor holder, tighten the M5 Hex Screws, adjust the spindle height so it sits about centered in the
holder, and then tighten the screw.
