Genmitsu 3020-PRO MAX CNC - Connect the Stepper Motors

2. Connect the Stepper Motors: Plug the X, Y, Z motor cables into the X- Motor, Y-Motor and Z-Motor port. (There are two ports for
connecting the Y axis motor, one is reserved for a Rotary 4th axis, you can plug into either Y axis port.)
X-axis Motor
19
X-axis Motor
Y-axis Motor Z-axis Motor
Y-axis Motor
Z-axis Motor
