Genmitsu 3020-PRO MAX CNC - Connect the Limit Switches

1. Connect the Limit Switches: Plug the X, Y, Z limit switch cable into X-, Y-, Z- port of the control board. There is a spare Z-limit switch
for replacement.
18
X-axis limit Y-axis limit Z-axis limit
