Genmitsu 3030-PROVer MAX CNC - Spindle Wiring Connection

2. Spindle Wiring
20
Wiring
Open the connector, connect the spindle red positive cable to the red positive cable, and connect the spindle black negative cable
to the black red negative cable, as shown in the figure.
Black-red
Negative Pole Cable
Red Positive
Pole Cable
Red Positive Pole Cable from Spindle
Black Negative Pole Cable from Spindle
Connector
