04 Product Functions and Introduction
12
Lift the front of the machine upward
Push the honeycomb panel from the front bottom of the machine to the inside
Push the honeycomb panel to the anchor point
Honeycomb panel usage area: 20W-400*400mm, 40W-390*390mm.
The bottom has a metal structure to quickly clean up residue and prevent laser burns on your items.
The zero point is consistent with the laser zero point, and with the X positioning bar, rapid positioning can be achieved.
