Electric Stand Introduction
1. Place the laser unit onto the Laser Stand. To adjust the height of the stand to calibrate laser focus, follow the
instructions below.
2. Place the engraved object on the pad, then pull down the focusing rod, rotate the Knurled Screw, and adjust
the height of the stand. Let the focusing rod touch the surface of the object, tighten the Knurled Screw, and retract
the rod after the ranging is completed.
Mainframe
Lifting Frame
Fixed Focus Lever
Engraving Object
08
Knurled
Screw
