7. OUTPUTS:
Output is disabled when this item is selected.
This output includes all shutdown alarm and warning alarm. When
warning alarm occurs, the alarm won’t self-lock; when a shutdown
alarm occurs, the alarm will self-lock until alarm is reset.
This output valid for gen-sets with stop solenoid. Pick-up when idle
speed is over, disconnect when ETS delay is over.
This output valid for the gen-sets with idle speed. It is active while
gen-set warming up when starter disconnecting. Also it is active to stop
gen-set completely while stop idle disconnecting.
This output controls preheat.
This output used for to control gen-set’s breaker.
This output used for control mains’ breaker. Only for GEC6120
models.
When close time is set as “0”, Open Breaker is disabled.
Activated when gen-set enter into warming up time. Disconnected
when raise speed auxiliary input active.
Activated when gen-set enter into stop idle or ETS solenoid stop
(shutdown alarm). Disconnected when droop speed auxiliary input
active.
Activated when gen-set is in normal running, disconnect when rotating
speed is lower than engine speed after fired.
Activated when the fuel level lower than the open threshold or low fuel
level warning is active; disconnected when the fuel level over the close
threshold and the low fuel level warning input is disabled.
Activated when gen-set enters into warming up time, and disconnectted
after cooling.
The controller is in Auto Mode.
Activated when shutdown alarm occurs.
When shutdown alarm and warn alarm occur, audible alarm is set as
300s. In audible alarm output duration, when panel any key or “alarm
mute” input is active, it can remove the alarm.
Active when genset is starting and disconnect when stop is completed.
Active when gen-set starting.
