GENPOWER FORTRUST 6110D - 8. INPUTS

No
Parameter
Description
20
Reserve
21
Reserve
22
Reserve
23
Reserve
24
Speed Raise Pulse
Output
Active while the unit entering into high-speed warming up.
25
Speed Drop Pulse
Output
Active while the unit entering into stop idling.
26
Oil Pump Control
Activated when the fuel level lower than the open threshold or low fuel
level warning is active; disconnected when the fuel level over the close
threshold and the low fuel level warning input is disabled.
27
Reserve
28
Reserve
29
Aux. Input 1
It is active when signal gets to Aux. Input 1
30
Aux. Input 2
It is active when signal gets to Aux. Input 2
31
Aux. Input 3
It is active when signal gets to Aux. Input 3
32
Aux. Input 4
It is active when signal gets to Aux. Input 4
33
Aux. Input 5
It is active when signal gets to Aux. Input 5
8. INPUTS:
No
Parameter
Description
0
Not Used
Input is disabled when this item is selected.
1
High Temperature
Shutdown
If the signal is active after safety run delay over, gen-set will
immediately alarm to shutdown.
2
Low Oil Pressure
Shutdown
If the signal is active after safety run delay over, gen-set will immediately
alarm to shutdown.
3
Warn Input
This input only warning, not shutdown.
4
Shutdown Input
If the signal is active, gen-set will immediately alarm to shutdown.
5
WTH STOP by Cool
During engine running and the input is active, if high temperature occurs,
controller will stop after high speed cooling; when the input is disabled,
controller will stop immediately.
6
Generator Closed
Auxiliary
This signal give information of gen-set is on or not. Connect the gen-set’s
breaker’s auxiliary port to this input.
7
Mains Closed
Auxiliary
This signal give information of mains is on or not. Connect the mains’
breaker’s auxiliary port to this input.
8
Inhibit WTH STOP
When it is active, high water temperature stop is inhibited.
