CONTROL BOARD REPLACEMENT:
The Genus
®
Spectra fly trap uses the universal control board which is
available from your local distributor.
1. Prepare the replacement universal control boards [see following
diagram].
Genus
®
Spectra: Two halves of the complete universal control board are
used. Tear off and discard section 4. Use one half of each board in the
upper and lower sections.
Genus
®
Spectra Compact: Only one half of the complete universal
control board is used in. Tear off and discard section 4. Use one half of
the board and keep the remaining half for future use.
To replace the control board, follow the procedure below:
1. Isolate unit from electrical supply before handling.
2. Open the front screen by lifting up and open to its full extent.
3. Remove the control board by gripping the tab at the base of the board,
lifting up and off the plate.
4. Take the replacement control board and refit ensuring it locates behind
the tabs of the plate. Remove the release paper.
5. Close the screen and reconnect the electrical supply.
