1.6.4
IMPORTANT PAGES CHAPTER 6
GEODIMETER SYSTEM 600
Backup of memory
As a safety measure always backup your memory to
protect yourself from memory loss. Ensure that your data
can be found in more files than one and if possible in
more than one place.
Backup is easily done with Program 54 which enables you
to transfer Job- and Area-files between the different Geo-
dimeter units or to a PC, see ”Software and Data
communication” for more information. You can also use
the PC-program Geotool, ask your local dealer for a
demonstration.
Reboot the keyboard unit
Measurements will be stored in the memory of the key-
board unit attached to the instrument. The data system is
designed to max. security with write protection of the
data memory and a backup of the working area of the
programs. If a lock up or an error of the program should
occur which cannot be resolved by just a restart of the
instrument, there is a new reboot action available:
1. Disconnect the keyboard unit from the instrument and
connect it to an external battery.
2. Start the keyboard unit by keeping the key and
depressed at the same time.
3. In the display will 2 options be available.
4. Choose 2. Reboot and a reboot will occur.
Note that in this case all functions will be reset and all self-made
U.D.S. will be lost.
Fast check of the collimation errors (only servo)
1. Aim at the point exactly.
2. Press the button.
3. Look at reticle. The difference in aiming represents the
value of the current collimation errors (dH and dV).
4. If you consider them too large we recommend you to
perform a test measurement (MNU 5).
General measurement hints
