Geodimeter 600 Pro - Data Output

2.7.3
DATA LOGGING CHAPTER 7 GEODIMETER SYSTEM 600
A standard table for output is set for each measurement
mode of the instrument. If a different output is required, 5
additional output tables can be specified by the user directly
from the keyboard. This is done with MNU 42, Create table
function.
The choice of the type of recording device that shall be used
for the transfer of the data - e.g. Internal memory on the
instrument or Serial for direct transfer via the tribrach
conatact to and from a computer - is done with MNU 41,
Select device function.
Different output tables or the same one can be activated for
more than one device simultaneously.
Standard output
Output of measured data from Geodimeter System 600 can
be set completely independently of the displayed data. The
standard output tables have been set for recording horizontal
angle, vertical angle and slope distance for the different mea-
suring modes. If output of other data is required, special
output tables can be set by the operator. The standard out-
put, Table 0 (see tab. 7:2, page 2.7.4), is adapted to the func-
tion of the different modes of measurement, while a User
Defined Table 1, 2, 3, 4 and 5 will be independent of choice
of mode.
Data Output
Control of data registration
4
MNU
Note! ☛
A com-
plete list
of Func-
tion and
labels
can be
found in
Appen-
dix A.
The instrument checks the validity of data before recording.
It checks, for instance, that the instrument is on target. This
can be deselected with Targ. test off? MNU 61 - i.e. that
measured angles and distances correspond to each other and
that a measured distance is not recorded twice. For more
information about eccentric objects, see "yellow pages"
2.2.7.
