July 14, 2015
14
5. Changing the Default Settings of Beeper and LED
You can change the default settings of the LED and the beeper by enabling a GV-AS210 /
2110 / 410 / 4110 / 810 / 8110 to externally control the LED and Beeper. Through the Web
interface, you can set the controller to trigger the red LED, green LED or beeper when the
specified alarm events occur.
The GV-AS Controller and the reader need to be connected through Wiegand interface. You
will have to:
1. Enable external control of the reader’s Beeper and LED by using the GV-R/RK/DFR
Config AP.
2. Wire the Beeper, Red LED and Green LED from the reader to the GV-AS Controller.
3. Specify the Beeper and LED settings for each door through the Web interface of GV-AS
Controller.
5.1 Setting up Beeper and LED on GV-R/RK/DFR Config AP
To enable the external controls of the Beeper and LED on GV-R/RK/DFR Config AP, the
reader needs to be connected to a computer through GV-COM, GV-Hub or GV-NET/IO Card
V3.1.
1. Start the GV-R/RK/DFR Config AP and select the COM port that is connected to the
reader.
Note: To see how to install the Config AP and how to identify the COM port of the reader,
refer to 3. Installing GV-R/RK/DFR Config AP and 4.1 Defining the ID Number and Setting
the Reader to Slave earlier in this installation guide
