GeoVision GV-SNVR User Manual

Getting Started
66
2
 Image Alignment: On the upper-right square of the Quad view, click any button from
, and the red circle appears. Use the to align the red circle with the edge of
the camera image. For details, see 5.1.7 Fisheye View.
Figure 2-54
 Camera Position: Select Ceiling, Wall, or Floor according to where the camera is
mounted.
 Reset: Restore to Quad view setting.
Use the to zoom in, zoom out or adjust the direction of the camera image.
2.8.6 Image Orientation
Note this section is only applicable to GV-SNVR0411 / 0412 / 0811 / 0812 / 1611 / 1612.
To rotate the image of a live or recorded video with the image orientation function, click the
camera name of a desired camera, select Image Orientation and choose the desired
rotation angle.

GeoVision GV-SNVR Specifications

General

Operating System	Embedded Linux
Video Output	HDMI, VGA
Network Interface	Gigabit Ethernet
USB Ports	USB 2.0
Remote Viewing	Yes
Protocols	TCP/IP, HTTP, HTTPS, DHCP, DNS, DDNS, PPPoE, SMTP, NTP, UPnP, RTSP, RTP, UDP, ICMP, IGMP
Video Compression	H.264, H.265, MJPEG
Hard Drive Capacity	Supports up to 10TB per HDD
Channels	16
