C. Gerhardt GmbH & Co. KG
26
VAPODEST 20
8 Maintenance
In case of necessary replacements, please make sure that only
original C. Gerhardt spare parts are used!
Tubing diagram
The pumps and the valves of the instrument are marked with refe-
rence numbers.
Descriptions of the structural components (rear - interior of instru-
ment):
1.... PVC-pipe 6x1 mm, 400 mm
2.... PVC-tubing 4/7 mm
3.... Diaphragm pump NaOH (pos. 6)
4.... Diaphragm pump H
2
O steam generator (pos. 5 )
5.... Silicone tubing 4/7 mm
6.... Inlet condenser, Silicone tubing 8/16
7.... Outlet condenser, Silicone tubing 8/16
8.... Ventilation glass
9.... Pinch-solenoid valve, steam (pos. 7)
10.... Novoprene-tubing 4,8x1,6 mm
11.... Verprene-tubing 4/8 mm
12.... PP-distributor with PP-thread
13.... PTFE-inlet tubing NaOH
14.... Steam generator
15.... Water inlet tubing 10/17 mm
16.... Magnetic valve cooling water (Pos. 8)
17 .... Outlet tubing, PVC 8/12 mm
18.... PVC-tubing 8/12 mm
19.... Level detector for chemical tank
20 .... PVC-pipe 10x1, 400 mm
