P.10

Tight

Loose

Installation Instructions

3. Put the back grill to “fan body”, align the cards slots of back grill and fan body.

Install the grill nut on the back grill and tight it clockwise.

Install the blade and align the card slots.

Install the blade nut and tight it anticlockwise.

Put the front grill on the back grill, tight it clockwise, and align the card slots.

TightLoose
