P.9
安裝說明 Installation Instructions 安裝說明 Installation Instructions
接電方法
由電箱獨立伸延一條適合之電線(見下表)至浴室
門外接駁獨立開關掣，再將電線伸延至熱水器
穿進灰色線夾接到電線排上分別接上水線(N)，
火線(L)，及地線( )等。
Electric Wiring
Use an independent wire (refer to table below)
leading from the meter box and connect it to an
independent on/off switch outside bathroom.
Extend the wire through the grey wire grip on the
water heater. Dismount the bottom plate and wire
up Neutral (N), Life (L) and Earth ( ) terminals.
發熱線功率 (千瓦)
HeatingElementRating(kW)
所需電源(安培)
ElectricCurrent(A)
電源線最低要求(平方毫米)
Wiring(mm²)
1.5kW 8A(單相1PE) 1.5mm²
2kW 10A(單相1PE) 2.5mm²
3kW 15A(單相1PE) 2.5mm²
4kW 20A(單相1PE) 4.0mm²
6kW 30A(單相1PE) 6.0mm²
8kW 40A(單相1PE) 10.0mm²
9kW 15A(三相3PE) 2.5mm²
12kW 20A(三相3PE) 4.0mm²
電源開關掣
設於熱水器外用以切斷電源供應之開關掣，應全
極切斷電源，兩極之間應保持最少3mm距離。
測試使用
水喉與電源接駁妥當及內膽注滿水後，便可進
行通電。此時指示燈會亮著，用戶便可將自動
恆溫旋鈕調校至最高度數。當溫度達到75℃
時，恆溫器即會自動停止加熱。選擇適當溫度
後不應以恆溫旋鈕當作開關掣使用，因此舉會
縮減該配件之使用壽命。
Power Switch
The external switch is used to completely
disconnect water heater from power supply.
It should disconnect all poles, and a contact
separation of at least 3 mm must be present.
Testing
Whenthepipingandwiringareconnectedand
innertankhasbeenlledupwithwater,switchon
the power. The indicator on the water heater will
be lit. Turn control knob to the desired temperature
(Max.temperatureis75°C).Donotusethecontrol
knob as an on/off switch.
