GESTRA UNA 38 - Page 39

39
Type of
connection
DN 15
(½")
DN 25
(1")
DN 40
(1½")
DN 50
(2")
L1 [mm (in)]
Flange PN160
215 (8.5)
230 (9.1)
235 (9.3)
245 (9.6)
ASME class
900/1500 flanges
240 (9.4) 250 (9.8) 260 (10.2) 280 (11.0)
Butt-weld end
170 (6.7)
170 (6.7)
170 (6.7)
170 (6.7)
Socket weld end
170 (6.7)
170 (6.7)
235 (9.3)
245 (9.6)
L2 [mm (in)]
Flange PN160
285 (11.2)
300 (11.8)
305 (12.0)
315 (12.4)
ASME class
900/1500 flanges
310 (12.2)
320 (12.6)
330 (13.0)
350 (13.8)
Butt-weld end
240 (9.4)
240 (9.4)
240 (9.4)
240 (9.4)
Socket weld end
240 (9.4)
240 (9.4)
305 (12.0)
315 (12.4)
Service dimension S [mm
(in)]
All
150 (5.9)
150 (5.9)
150 (5.9)
150 (5.9)
Weight [kg (lb)]
Flange
67 (147.7)
70 (154.3)
70 (154.3)
78 (191.8)
Socket weld end,
butt-weld end
65 (143.3) 65 (143.3) 65 (143.3) 65 (143.3)
