10
Installation instructions
5018606-00 Rev.C Edition 0704
Function check
• Check that the machine is connected to the correct voltage and the waste,
water, steam and condensate connections are correctly connected. Open the
valves for water and steam.
• Fill the detergent and rinse aid containers and place alarm sensors in the
containers.
Machines with double doors have a system of interlocks to ensure that only one
door can be opened at a time.
If the soiled-side door cannot be opened, check that the clean-side door is
closed. The clean-side door can only be opened if the completed process has
been approved and the door on the soiled side is closed and locked.
• Place a wash rack in the wash chamber and close the door.
• Choose a program where dosing is done from all detergent and rinse-aid
containers and start the machine (see Instructions for use).
• Check that the machine draws water.
Note: If the machine has a distilled water pump, make sure that the pump has been filled
with water so that it can deliver enough pressure to open the distilled water valve.
NOTE:
On starting, there must be water in the circulation pump. If there is no water in the pump,
the shaft seal may suffer damage.
• Check that the circulation pump is rotating the right direction as indicated by the
arrow on the pump motor. If not, isolate the power, change the phase sequence
at the electrical connections and restart the machine.
Figure 10. Circulation pump
• Check that the dosing pumps work at the right time in accordance with the
program description in the instructions for use and that detergent is drawn off.
• While the program is running, check that the door(s) cannot be opened.
Installation
V1426
