GEZE Slimdrive EMD-R Installation And Service Instructions

Slimdrive EMD Invers
5
Fundamental safety precautions
2 Fundamental safety precautions
2.1 Intended use
The Slimdrive EMD Invers door drive is designed for the automatic opening and closing of single-action swing
doors.
The Slimdrive EMD Invers is designed solely for use
à in dry rooms
à In entrances and interior areas of pedestrian trac in commercial plants and public areas,
à in private areas.
The Slimdrive EMD Invers
à is designated for use on SHEV fresh air supplies
à is designated for use on escape and rescue routes
à must not be used on re or smoke protection doors
à must not be used for potentially explosive areas.
Any other use than the intended use, such as permanent manual operation with the drive de-energised, as well
as any modication to the product, is not permitted.
2.2 Safety notices
à The mandatory installation, maintenance and repair work must be performed by properly trained personnel
authorised by GEZE.
à The country-specic laws and regulations are to be observed during safety-related tests.
à If unauthorised changes are made to the system, GEZE cannot be held liable in any way whatsoever for any
resulting damage, and the statement of approval for use in escape and rescue routes is no longer valid.
à GEZE does not accept any warranty for combinations with third-party products.
à Furthermore, only original GEZE parts may be used for repair and maintenance work.
à The connection to the mains voltage must be made by a professional electrician. Perform the power connec-
tion and equipment earth conductor test in accordance with VDE 0100 Part 610.
à Use an on-site automatic cut-out as the line-side disconnecting device, the dimensioning of which is matched
to the type, cross-section, type of routing and ambient conditions of the on-site power supply circuit. The
automatic cut-out must have at least 4A and max. 16A.
à Protect the display programme switch against unauthorised access.
à In compliance with Machinery Directive 2006/42/EC, a risk analysis must be performed and the door system
identied in accordance with CE Marking Directive 93/68/EEC before the door system is commissioned.
à Observe the latest versions of directives, standards and country-specic regulations, in particular:
à ASR A1.7 “Directives for doors and gates”
à DIN EN 16005 “Power operated pedestrian doorsets – Safety in use – Requirements and test methods”
à VDE 0100; Part 610 “Erection of low-voltage installations”
à Accident prevention regulations, especially DGUV regulation 1 “Principles of prevention” and DGUV regula-
tion 3 “Electrical installations and equipment”
à DIN EN 60335-2-103 "Safety of electrical devices for home use and similar purposes - Part 2-103: Special
requirements for drives for gates, doors and windows”
à DIN 18263-4 “Building hardware - controlled door closing devices - Part 4: Automatic swing door operators
with self-closing function”
à DIN 18650 “Building hardware - Powered pedestrian doors”
à DIN 18040 “Barrier-free construction”
The product should be installed or incorporated in such a way that eortless access to the product is guaranteed
during any repairs and/or maintenance, and that any removal costs do not stand out of economic proportion to
the value of the product.

GEZE Slimdrive EMD-R Specifications

General

Brand	GEZE
Model	Slimdrive EMD-R
Category	Door Opening System
Language	English
