Instruction manual
Electric Actuators Type EA15-250
3.9 Technical specifications
3.9.1 Specifications
Specifications EA15 EA25 EA45 EA120 EA250
Power input max. 45 VA 45 VA 65 VA 60 VA 70 VA
Current (calculated) 0.3A at 100V
0.13A at 230V
0.35A at 100V
0.15A at 230V
0.55A at 100V
0.24A at 230V
0.5A at 100V
0.22A v 230V
0.55A at 100V
0.26A at 230V
1.7A at 24V 1.7A at 24V 2.5A at 24V 2.3A at 24V 2.7A at 24V
Nominal torque Mdn
(peak)
10 (20) Nm 10 (25) Nm 20 (45) Nm 60 (120) Nm 100 (250) Nm
Duty cycle 40% @ 25°C/
15min
100 % 50 % 50 % 35 %
Cycle time s/90° at Mdn 5 s 5 s 6 s 15 s 20 s
Flange fitting F05 F05 F05 F07 F07
Tested cycles (at 20 °C
and Mdn)
150 000 250 000 100 000 100 000 75 000
Weight 1.9 kg 2.1 kg 2.2 kg 3.3 kg 5.0 kg
Feedback relays Bistable changeo-
ver contacts; max.
2A at 30V DC
Mono-stable change-over contacts
Either max 6A @ 230VAC or 24VDC, no mixed voltage potentials allowed!
Actuating angle Max. 355°, set to 90°
Power Supply AC: 100 – 230 V, 50/60 Hz
AC/DC: 24 V, 50/60 Hz
Supply voltage tolerance +15 % / -10 %
Protection class IP68 per EN 60529
Designed for wet & dry locations (NEC), designed for indoor use
(UV light may cause discoloration)
Pollution degree Operation: Pollution Level 3
Commissioning (open cover):
Only in controlled environments of pollution level 2
Overload protection Current/time dependent, resetting
Overvoltage category II
Fuse Internal SMD fuse: 24 V DC: 4A, 230 V DC: 1.25A; not replaceable.
Req. external breakers on all live wires:
Rated Current: max. 16A
Trip Curve: C,
Standards Compliance: cUL 489, CSA C22.2 No. 5.1, IEC 60947-2
Ambient temp. -10 °C to +50 °C (14°F to 122°F)
Max. installation altitude 2000m above sea level (AMSL)
Required connecting
cable
AWG 18-16, UL/cUL AWM 4486 min. 125°C 600V , outside diameter 7-12 mm (cable glands), 4-9mm
(DIN-connectors). Tightening torque 6-8 Nm.
Allowable humidity Max. 90 % relative humidity, non condensing
Housing material Housing: PP-GF (POLYFLAM, RPP 4225 CS1)
Inspection glass: Udel P-1700 (CL2611)
