57
Cycle time extension (Vario)
Description Technical data Code
Cycle time extension 199 190 080
The cycle time extension increases the cycle time of the
electric actuator. To do this, the actuator rides clocked to
the end positions (OPEN or CLOSED).
The corresponding values are contained in the following
table. These values apply for 90° angle. Cycle time without
BCD: 5s for 90° (EA21); 15s for 90° (EA31); 25s for 90° (EA42)
Switch setting Cycle time monitoring [s]
EA21 EA31 EA42
0 Delivery position 8 20 30
1 12 25 35
2 15 30 40
3 19 35 45
4 25 40 50
5 30 50 55
6 35 60 65
7 35 60 75
The switch positions 8 – 9 have the function of position 7.
The extension of the cycle time is also active in case of failu-
re or reset operation.
