GFA LB 700 - Control-device connection diagram for T801 (optional)

24
6 Control-device connection diagram for T801 (optional)
S14 “Open” control button W Connection cable
S15 “Stop” control button X Terminal strip
S16 “Close” control button X20 Plug-in connector
T801 Control unit
7.11 7.2
3 7.3 4
X
7.4 7.5
1.5
N
1.6
L
X
X20
S14
S15
S16
8K2
2 5 6
gegnbrws rsgrPE12
1
23456
ws br gn ge gr rsPE12
T 801
