2 | Safety G 1111 / G 1114
6 / 22 B-H88.0.1X.DK2-1.2
_
2.3 Safety instructions
_
This product does not belong in children's hands!
2.4 Intended use
_
_
_
The device measures the absolute pressure in the air, clean water or in non-
corrosive/non-ionising gases. A direct measurement of the environmental pressure can
take place or the measurement pressure is taken with a suitable hose connected to the
port. Relative measurements can also be conducted with the integrated special func-
tion NVLL.
Applications include:
Barometric measurements (e.g. weather)
Barometric measurements (e.g. weather)
Vacuum measurements (down to 0.0 hPa
abs., negative pressure via hose or even
with complete device evacuation)
Vacuum measurements (down to 0 hPa
abs., negative pressure via hose or even
with complete device evacuation)
Pneumatic measurements (up to 14000
hPa abs. or 14 bar abs.)
The pressure connection is made at the supplied interchangeable pressure connection
ports with suitable hoses - 4 different connection options are available as standard,
many other connection options can be used easily and reliable with G 1/8 adapters.
The device must only be used under the conditions and for the purposes for which it
was designed.
It must be handled with care and used according to the technical data (do not throw,
strike, etc.). Suitable measures must be used to protect the pressure connections and
be protected from dirt.
_
Complete evacuation see Vacuum measurements [page 13].
