E. DIP #4 DUAL (BI-PARTING) GATE OPENING SEQUENCE. The gate opening sequence for dual

gate opener systems only is determined by DIP#4. This DIP switch does not apply to single gate opener

installations

NOTE

The SECOND arm will always CLOSE ﬁrst before the FIRST arm.

DIP Switch # OFF Position ON Position

4 Delay Open (Factory Default):

FIRST arm will open before the

SECOND arm.

Simultaneous Open: Both the FIRST arm and the SECOND arm will

simultaneously OPEN.

If Gate Lock is installed, the system will ignore this DIP switch

setting and default to delay open on the SECOND arm.

TURN CONTROL BOX ON. YOU SHOULD HEAR A SERIES OF BEEPS AS THE SYSTEM

IS TURNED ON

STEP 11. Locate the jog buttons at the top right of control box to test the arm and connections.

ARM EXTENDED

OUT 3-4 INCHES
