NR. DESCRIPTION REMARKS Q’TY PER BIKE
1 Front triangle 1
2 Seat stays 1
3 Chain stays 1
4 Lower shock mount Set 1
4-1 Fixing bolt M6x1x40mm. 1 pc. per set
4-2 Washer 13.5x6.4x1.2mm.
2 pcs per set,
same as 8-2.
4-3 Nut M6 1 pc. per set
5 Fixing bolt upper shock mount M8x1.25x65mm. 1
6 Pivot parts set Seat tube - linkage plates 2
6-1 Bolt M10x1 1 pc. per set
6-2 Bearing 1 pc. per set
7 Pivot parts set Seat stays - linkage plates 2
7-1 Washer 14x10x3mm.
1 pc. per set,
same as 9-3.
7-2 Bearing
1 pc. per set,
same as 9-2.
7-3 Fixing bolt 10x27/29mm. 1 pc. per set
8 Pivot parts set Chain stays - bottom
bracket
1
8-1 Fixing bolt M6x1x14mm. 1 pc. per set
8-2 Washer 13.5x6.4x1.2mm.
1 pc. per set,
same as 4-2
8-3 Bearing 2 pcs per set
8-4 Washer 18x10.1x3.5mm. 2 pcs per set
8-5 Nut 67mm. alu. 1 pc. per set
9 Pivot parts set Seat stays - dropouts 2
9-1 Fixing bolt 10x20.5/22.5mm. 1 pc. per set
9-2 Bearing
1 pc. per set,
same as 7-2.
9-3 Washer 14x10x3mm.
1 pc. per set,
same as 7-1.
10 Linkage plates Set L and R 1
11 Rear shock Incl. hardware 1
12 Chain guard CG01 1
13 Bolt M4 for linkage plate bearing 2
14 Replaceable dropout Incl. bolt and nut 1
