ITEM PART # DESCRIPTION QTY.
1 06100 Crankcase 1
2 13000 Oil Filler Cap Assembly 1
4 07243 Cover, Crankcase 1
5 07244 O-Ring, Crankcase Cover 1
8 01008 Oil Dip Stick 1
9 01009 O-Ring, Dip Stick 1
10 01010 Screw, Crankcase Cover 4
11 01011-0400 Spring Washer 4
12 07109 Oil Drain Plug 1
13 07182 Gasket, Oil Drain Plug 1
14 07245 Bearing Cover 2
15 07247 Seal, Crankshaft 2
16 07627 O-Ring, Bearing Cover 2
17 07114 Hex Screw, Bearing Cover 9
20 07248 Roller Bearing, Tapered 2
20A 07249 Shim 2
20B 06962 Fitting Disc 2
21 07250 Shaft Protector 1
22 07251 Crankshaft 1
23 07252 Key 1
24 07253 Connecting Rod 3
25 07596 Crosshead Complete 3
28 07255 Crosshead Pin 3
29A 07256 Centering Sleeve 3
29B 07262 Ceramic Plunger, 20mm (MP4120W) 3
29B 13046 Ceramic Plunger, 24mm (MP4124W) 3
29B 07261 Ceramic Plunger, 30mm (MP4130W, 3
MP4130HK)
29B 13005 Ceramic Plunger, 28mm (MP4135W) 3
29C 13007 Bolt, Sold only w/#07258 3
29D 07258 Seal Washer 3
30 06136 Flinger 3
31 07260 Crankcase Oil Seal 3
35A 07263 Rear Support Ring (MP4120W) 3
35A 06079 Rear Support Ring (MP4124W) 3
35B 06064 Rear V-Sleeve (MP4120W) 3
35B 06080 Rear V-Sleeve (MP4124W) 3
35C 07265 Rear Pressure Ring (MP4120W) 3
35C 06081 Rear Pressure Ring (MP4124W) 3
35D 07266 Rear O-Ring (MP4120W) 3
36 07267 Snap Ring 3
39 07268 Pressure Ring (MP4120W) 3
39 06082 Pressure Ring (MP4124W) 3
39 07271 Pressure Ring (MP4130W) 6
39 13013 Pressure Ring (MP4135W) 6
40 07322 V-Sleeve (MP4120W) 3
ITEM PART# DESCRIPTION QTY.
40 06083 V-Sleeve (MP4124W) 3
40 07272 V-Sleeve (MP4130W) 6
40 05687 V-Sleeve (MP4135W) 6
40 06137 V-Sleeve (MP4130HK) 6
40A 07272 V-Sleeve (MP4130HK) 3
41 07270 Support Ring (MP4120W) 3
41 06084 Support Ring (MP4124W) 3
41 07273 Support Ring (MP4130W) 6
41 06652 Support Ring (MP4135W) 6
41A 07329 Spacer (MP4120W, MP4124W) 3
41A 07274 Intermediate Ring (MP4130W,
MP4135W) 3
42 07275 Tension Spring (MP4120W/MP4124W) 3
42 07353 Tension Spring (MP4130W, MP4135W) 3
42A 06102 Tension Plug (MP4120W/MP4124W) 3
42A 06103 Tension Plug (MP4130W, MP4135W) 3
42B 07332 O-Ring (MP4120W/MP4124W) 3
42B 07354 O-Ring, Tension Plug (MP4130W,
MP4135W) 3
43 06104 Manifold Head (MP4120W/MP4124W) 1
43 06105 Manifold Head (MP4130W, MP4135W) 1
44 07280 Valve Seat 6
44A 07281 O-Ring, Valve Seat 6
45 07282 Valve Plate 6
46 07283 Discharge Valve Spring 3
46A 06959 Inlet Valve Spring 3
47 07284 Spring Retainer, Discharge 3
48 06108 Plug, S.S. (MP4120W, MP4124W) 3
48 07356 Plug, Brass (MP4130W, MP4135W) 3
48A 07332 O-Ring, Plug 3
49 06109 Stud, Manifold 6
49A 07319 Shim, Stud 2
50 07158 Nut, Manifold Stud 6
50A 07159 Spring Washer 6
51 06110 Spacer 3
52 06111 Valve Housing (MP4120W/MP4124W) 3
52 06112 Valve Housing (MP4130W) 3
52A 07329 Spacer Ring (MP4120W) 3
53 12057 O-Ring (MP4120W/MP4124W) 3
53 07332 O-Ring (MP4130W) 3
53A 12027 O-ring (MP4120W) 3
54 06115 Spring Retainer, Inlet 3
57 13020 Disc for Crankshaft 1
MP SERIES PARTS LIST AND REPAIR KITS
Inlet Valve Assembly Kit # 09062
Item Part # Description Qty
42B 07354 O-Ring Tension Plug 3
42B 07332 O-Ring Tension Plug 3
44 07280 Valve Seat 3
44A 07281 O-Ring, Valve-Seat 3
45 07282 Valve Plate 3
46A 06959 Valve Spring 3
53 12057 O-Ring 3
53A 12027 O-Ring 3
54 06115 Spring Retainer 3
Discharge Valve Assembly Kit # 09043
Item Part # Description Qty
42B 07332 O-Ring, Tension Plug 3
44 07280 Valve Seat 3
44A 07281 O-Ring 3
45 07282 Valve Plate 3
46 07283 Valve Spring 3
47 07284 Spring Retainer 3
Plunger Packing Kits
MP4120W # 09044
Item Part # Description Qty
40 07322 V-Sleeve 3
35B 06064 Rear V-Sleeve 3
MP4124W # 09300
Item Part # Description Qty
40 06083 V-Sleeve 3
35B 06080 Rear V-Sleeve 3
MP4130W # 09042
Item Part # Description Qty
40 07272 V-Sleeve 6
MP4135W # 09665
Item Part # Description Qty
40 05687 V-Sleeve 6
MP4130HK # 09664
Item Part # Description Qty
40 06137 V-Sleeve, High Temp 6
40A 07272 V-Sleeve 3
5
